应用于氟化钙、氟化镁、铌酸锂、钽酸锂等光学晶体及碘化钠、碘化铯、锗酸铋等闪烁晶体还可用于生长金属卤化物钙钛矿等新型晶体材料。

       It is applied to the growth of optical crystals such as calcium fluoride, magnesium fluoride, lithium niobate, lithium tantalate, and scintillation crystals such as sodium iodide, cesium iodide, bismuth germanate. It can also be used to grow new crystal materials such as metal halide perovskites.

主要技术指标

◆ 加热温区:4个，实现不同温度梯度

◆ 最高加热温度:1200℃

◆ 连续工作温度:1100℃

◆ 控温精度：±0.1℃

◆ 恒温区精度：±0.2℃

◆ 真空度:10-2 torr(采用机械泵)，10-5 torr(采用分子泵系统)

◆ 伺服提拉装置

◆ Heating zones: 4, enabling different temperature gradients

◆ Maximum heating temperature: 1200℃

◆ Continuous working temperature: 1100℃

◆ Temperature control accuracy: ±0.1℃

◆ Constant temperature zone accuracy: ±0.2℃

◆ Vacuum degree: 10-2 torr (using mechanical pump), 10-5 torr (using molecular pump system)

◆ Servo lifting device
