旋转管式炉是一款适用于金属氧化物或者其它无机材料等细微颗粒粉末材料的实验和生产，是粉末冶金，陶瓷，耐火材料，锂电正负极材料，新能源等行业颗粒粉末烧成、煅烧，测定材料在一定气氛条件下的周期式生产的设备。

       The rotary tube furnace is suitable for the experiments and production of fine granular powder materials such as metal oxides or other inorganic materials. It is a periodic production equipment used in industries like powder metallurgy, ceramics, refractory materials, lithium - ion battery cathode and anode materials, and new energy for the firing and calcination of granular powders and for determining the properties of materials under certain atmospheric conditions.

主要技术指标Key parameters

◆ 加热区：三温区独立控温

◆ 工作温度：RT-1100℃

◆ 最高温度：1200℃

◆ 加热速率：0-20℃/min，可根据实际使用设置升温速率

◆ 控温精度：±1ºC

◆ 可倾斜角度：0-10度(可调)

◆ Heating zones: Three temperature zones with independent temperature control

◆ Operating temperature: Room temperature (RT) - 1100ºC

◆ Maximum temperature: 1200ºC

◆ Heating rate: 0 - 20ºC/min, and the heating rate can be set according to actual use

◆ Temperature control accuracy: ±1ºC

◆ Tiltable angle: 0 - 10 degrees (adjustable)
